SBC SERIES
The SBC series is an all-weather multi-functional crane in the field as an electric baby crane.
Hydraulic electric power up to 2nd stage / Manual operation of 3rd stage boom
SBC SERIES
The SBC series is an all-weather multi-functional crane in the field as an electric baby crane.
Hydraulic electric power up to 2nd stage / Manual operation of 3rd stage boom
Electronic
Brake
Safety
Guard
Robust
durability
Safety
Certification
SBC Features
_ AC motor & system applied (quiet driving without vibration and noise)
_ Handle EM switch (prevents operator jamming due to emergency stop)
_ Electric driving & Boom electric rotation
_ Fall prevention outrigger
SBC-1000
Load Capacity
300 / 500 / 1,000
boom length
2,300 / 1,200 / 2,350
Turning Radius
1,997
Model
Unit
SBC-1000
1-Stage
kg
1,000
Load capacity
2-Stage
kg
500
3-Stage
kg
300
Length
mm
980
Platform size
Width
mm
960
Height
mm
270
Oveall Length
mm
2,300
Overall Width
mm
1,200
Overall Height
mm
2,350
Turning radius
mm
2,000
1-Stage
mm
1,000
Boom Length
2-Stage
mm
1,060
3-Stage
mm
640
1-Stage
mm
2,700
Boom Height
2-Stage
mm
3,300
3-Stage
mm
3,800
Boom Turning Angle
Degree
180
Boom turning type
-
Hydralic
Power
-
DC24V
With Load
km/h
4 ~ 5
Travel Speed
Without Load
km/h
5 ~ 6
Boom
kW
2
Motor
Drive
kW
1.1
Boom Turning
-
H-100
Battery
-
24V x 268Ah/5Hr
Charger
-
AC 1Φ x 220V x 60Hz
Control System
-
F.E.T
🔹 The above appearance and specification are subject to change without prior notice
